| No. | Name | Item | Spec. |
| 1 | Drill head | Torque/rotating speed | 24KNm/85rpm |
| 2 | 12KNm/170rpm | ||
| 3 | Screwing off torque | 24 KN·m | |
| 4 | Swing angle | 0--80° | |
| 5 | Stroke | 12.5m | |
| 6 | Spindle dia. | φ70mm | |
| 7 | Feeding system | Lifting force/speed | 475KN/25 m/min |
| 8 | Feeding force/speed | 110KN/70 m/min | |
| 9 | Drilling capacity | Drill rod dia./drilling depth | φ89mm/2400m |
| 10 | Drill rod dia./drilling depth | φ114mm/1600m | |
| 11 | Drill rod dia./drilling depth | φ127mm/1000m | |
| 12 | Crane | Lifting force | 30kN |
| 13 | Steel wire diameter | φ10mm | |
| 14 | Drum capacity | 120m | |
| 16 | Hole diameter of the wellhead | max. | φ650mm |
| 17 | Diesel engine | Power | 310KW |
| 18 | rotating speed | 2300rpm/min | |
| 19 | Chassis | Max. climbing angle | 30° |
| 20 | Max. speed | 2 km/h | |
| 22 | Transportation dimensions | L/W/H | 11500x3200x3400 mm |
| 23 | Weight | 28 t |
